Name: 3/6kW 230V HH Series All In One Floor Mounted Energy Storage System
Brand: Marsrock Energy Storage Website
SKU: HH-3/6kW
Availability: InStock
Rating: 5 (1 reviews)

No.HH-3/6kW

The HH series floor mounted All-in-one solar energy storage system has a large capacity, high efficiency, built-in BMS protection system, suitable for household use.

Battery Capacity

5000Wh/10000Wh

Rated Power

3kW/6kW

Rated Output Voltage (V AC)

208/220/230/240V AC(Settable)Default230V

Size(mm)

442*132*944/508*132*999

Weight

42.5kg/75kg

Rated Power:

3kW

6kW

GET A QUOTE

Add to Quote List View Quote List

Description

Special Reminder:
The indicated global retail price only for your reference. Contact with us to get more discount and its current inventory quantity of us which located in your country.

Feature

Adopting vertical structure, it has high stability and can ensure stable operation under various environmental conditions.
Adopting advanced inverter technology with high conversion efficiency, which can reduce energy loss.
Easy to maintain, convenient for users to view and set various parameters.
Strong adaptability: Vertical inverters are usually waterproof, dustproof and sunproof, and can adapt to various environmental conditions.
Strong scalability, can increase or decrease the power capacity according to the actual needs.

Technical Parameter

	Battery Capacity	5000Wh	10000Wh
	Rated Power	3kW	6kW
Parallel Conn Ect	Max Parallel Connection Allowed	/	9
Utility Mode	Input Voltage	170~280V AC	170~280V AC
	Frequency	40~70Hz,Default	40~ 70Hz, Default
	Overload/Short Circuit Protection	20A	40A
	Maximum Efficiency	99.50%	99.50%
	Biggest Bypass Overload Current	20A	40A
Inverter Mode	Output Voltage Waveform	Pure Sine Wave
	Power Factor	0.9PF	1PF
	Rated Output Voltage (V AC)	208/220/230/240V AC(Settable)Default230V
	Output Frequency Range(Hz)	50.0 /60.0 Hz (Settable)Default 50Hz
	Maximum Efficiency	>93%	>94.5%
	Battery Voltage	25.6V	51.2V
	Compatible Battery Type	Lead-acid/lithium Electricity
Utility Charging	Maximum Charging Current	50A	80A
PV/Battery Charging	Largest PV Open Circuitvoltage	85V	500V
	PV Operating Voltage Range	30~80V	120~430V
	Largest PV Input Current	50A	18A
	Largest PV Power Input	/	5500W
	Solarcharging Current Range	10~50A	2~80A
Specifications	Size(mm)	442132944	508132999
	Weight	42.5kg	75kg
